Product Details:
Payment & Shipping Terms:
|
| Screen Size: | 8 Inch | Screen: | Multi-touch Capacitive Screen |
|---|---|---|---|
| Operation System: | Android 6.0|7.1|8.0|9.0 | CPU: | Quad Core|octa-core 1.6GHz |
| RAM: | 1GB|2GB|4GB | ROM: | 16GB|32GB|64GB |
| OSD Language: | Multi-language,English/Russian/Spanish/French/Portuguese/Arabic/Dutch Etc | GPS: | Support |
| Bluetooth: | Support | Dual Zone Function: | SUPPORT |
| Steering Wheel Control: | Supported | WiFi: | Built In |
| CarPlay: | Optional&Support By USB | DSP: | Optional |
| Built-in 4G SIM: | Optional | Android Auto: | Support By USB |
| USB: | Support | Warranty: | 12 Months |
| FM|AM Radio: | Built In | Plug&Play: | Yes |
| High Light: | volkswagen dvd player,dvd gps navigation system |
||
8-inch Volkswagen Seat Ibiza 2018 Android Autoradio GPS Navigation Multimedia system with built-in FM WiFi Bluetooth SWC Mirror-Link DSP CarPlay supports Rear Camera DVR Panoramic system DAB+ DVR OBD 4G SIM
General
Car make: Volkswagen Seat Ibiza 2018
Pin-to-Pin connectors and standard wiring harnesses for plug & play.
Support original Steering Wheel Control.
Support Dual Zone function.
Support micro SD cards, and external USB flash.
Operating System
Multiple Android OS options: Android 64-bit 6.0|7.1|8.1|9.0 OS.
Multiple hardware options: Quad-core|Octa-core CPU with 1GB|2GB|4GB RAM and 16GB|32GB|64GB ROM.
Multiple OSD language options: English, Russian, Arabic, German, Spanish, French, etc.
Display
8.0-inch capacitive multi-touch touch screen.
Multi-color RGB backlights.
Brightness control available.
Support screen display turned off while the unit keeps running.
Multimedia
Support upto 4 x 45W Surround Stereo|Subwoofer output power and multiple EQ modes.
Built-in DSP (optional).
Support Aux in/out.
Navigation
Built-in GPS|A-GPS|Glonass.
Support multiple Android apps for navigation.
Radio
Built-in FM|AM Radio Tuner with RDS supported.
Support external DAB+ Tuner via USB.
Connectivity
Built-in WiFi and support Hotspot for internet sharing.
Support external 3G/4G dongle by USB or built-in 3G/4G SIM for internet access.
Built-in mirror-link or built-in Android Auto|Apple CarPlay(optional) for connecting with Android|IOS smartphone.
Built-in Bluetooth for hands-free calling and music streaming.
Optional features|parts
Rear View Camera | Digital TV Receiver | DVR | Bluetooth OBD | iPod ready stereo | Apple CarPlay | Google Android Auto | USB DAB+ tuner | 4G dongle, etc.
Android specifications:
| System | |||
| Operating System (OS) | Android 4.4|6.0|7.1|8.1|9.0 | CPU | Cortex A7 Quad|Octa Core 1.6GHz |
| Memory/RAM | 1GB|2GB|4GB | Mirror-Link | Built in |
| Memory/ROM | 16GB|32GB|64GB | CarPlay/Android Auto | Optional |
| Max.Micro SD Capacity Supported | 1TB | DVR(Optional) | Support |
| Steering Wheel Control | Support (CANBUS needed) | TV Receiver(Optional) | Support Analog|Digital TV( DVB-T, ISDB-T,DVB-T2) |
| OSD Language Options | English, Russian, Arabic, German, Spanish, French, Thai, Italian, Vietnamese,etc. | ||
| Display | |||
| Screen Type | HD LCD-TFT, Scrape-prevent, Multiple Touch, Digital Capacitive screen | Screen Size | 8 inch |
| Resolution | 1024*600 | ||
| Navigation | |||
| Navigation | Built-in GPS/A-GPS and Glonass | Maps Storage | Built in or external SD card |
| Navigation Softwares Supported | TOMTOM, ROUTE66, IGO, NAVITEL,SYGIC, etc | Navigation Language | Depends on map software options |
| Others | Music/Radio/Bluetooth…can still work when GPS navigation is working | ||
| Network | |||
| 3G/4G-LTE | Supported, external 3G/4G dongle via USB needed | WiFi | Built in |
| Bluetooth | |||
| Bluetooth | Built in | Support | A2DP and Bluetooth OBD |
| Audio/Video | |||
| Audio/Video | Support most mainstream audio/video formats | Reversing Camera(Optional) | Support |
| Audio Signal-to-Noise Ratio | ≥85dB | Reversing Video Display | Quick switch within 2s |
| Radio | |||
| RDS | Support | Radio Response Bandwidth | AM: 522~1620 KHz, FM: 87.5~108 MHz |
| Station Preset Qty. | 36 Preset Radio Stations (FM: 3*6, AM: 3*6) | Radio Tuner | FM|AM |
| Amplifier | |||
| Amplifier Output Power / Channel Qty. | 45W*4 | Subwoofer | Support |
| EQ Modes | Normal, Jazz, Pop, Classical, Rock, News, Urban, Techno | Audio Output Channel | Audio 5.1 |
| Loudness Control | Yes | ||
| Mechanical | |||
| Form Factor | In-Dash | Audio Output | 4 Channels |
| Enclosure Type | 1 DIN | Subwoofer Output | 1 Channel |
| Video Input | 3 Channels, 1 for DVR, 1 for Camera, 1 for Aux in | Antenna | 2 totally:1 for GPS,1 for WiFi |
| Video Output | 1 Channel | USB | 2 Channes, USB3.0 |
| Audio Input | 2 Channels | ||
| Electrical | |||
| Power On | 16S~20S, quick booting up | Standby Current | ≤10mA |
| Power Off | Within 2S | Max. Operating Current | 10A |
| Shut off Display | Press POWER shortly to activate | Rated Working Voltage | DC12V |
| Anti Shock | Mechanical anti-shock & Electronic anti-shock | Operating Voltage Range | 10.8V ~16V |
| Environmental | |||
| Operating Temperature | -20°C to +70°C | Storage Temperature | -30°C to +80°C |
Why Astral Electronics?
1. OEM factory since 2009, with years of experiences in working with car manufacturers or well-known brands.
2. Hundreds of models available for different car brands, and keep releasing new products regularly.
3. Support Customization, and developing special designs as required available.
4. Quality guarantee by Systemized & Standardized quality system: OCA lamination for screen assembly, 8-plus hours aging test, high/low temperature test, Vibration test, 100% QC passed before delivery, etc.
5. CE/RoHs approved products, and other certificates available.
6. Multiple material sources to ensure stable supply and on-time delivery.
7. Local technical support negotiable.
